LED Solar Light
Home / LED Series / LED Solar Light / FSY Single CCT PIR Solar Bulkhead
  • FSY Single CCT PIR Solar Bulkhead
  • FSY Single CCT PIR Solar Bulkhead
LED Solar Light

FSY Single CCT PIR Solar Bulkhead

The FSY Series Round Solar Bulkhead uses a remote solar panel connected by a 3 m cable, so the panel can be installed wherever the light is best while the fixture itself goes exactly where illumination is needed — flexible positioning with no extra wiring required.

The built-in PIR sensor increases brightness automatically when motion is detected, providing both illumination and a visible safety cue, then returns to low-level lighting or switches off once the area is clear again, helping extend battery life. The single-CCT version skips any colour-temperature switching, making it a good fit for sites that just need consistent nighttime lighting without extra fuss.

This light suits gardens, corridors, porches and exterior walls as supplementary outdoor security lighting, and is particularly useful for residential complexes and shared walkways where a consistent lighting look matters.

On specifications, it offers 800/1200/1600 lm output options; the PIR sensor covers a 100° detection angle at a 6–10 m range; it's powered by a 3.3 W solar panel and a 3.7 V 2000/3000/4000 mAh lithium battery; and IP65 water resistance with an IK08 impact rating supports up to 18 hours of nighttime operation.

Overview

1. 800/1200/1600 lm options with a single CCT.
2. PIR sensor: 100° detection angle and 6–10 m range.
3. 3.3 W solar panel; 3.7 V 2000/3000/4000 mAh Li-ion battery.
4. IP65, IK08; up to 18 h of night light operation.

Are these lights manufactured by you? Are you a factory or a trading company?
Can you do OEM or ODM?
What is your main market?
What certification do you have?
Is it possible to print my LOGO on led light product?
What about the energy saving effect and life of LED lightings?
Can I have a sample order for led lights?
What is the Payment?
What about the lead time?
Is there an MoQ limit if buy led lights?
How to ship? And how long does it take to transport?
How to deal with the faulty?
Non PIR PIR Plug-in PIR

Non PIR

Model No. Power(W) Voltage CCT Lumen Output(lm) Dimensions(mm)
FSY5Y-B83S 5w AC 220-240V 3000K/4000K/6500K 3CCT adjustable 800 φ214*79mm
FSY8Y-B83S 8w AC 220-240V 3000K/4000K/6500K 3CCT adjustable 1200 φ214*79mm
FSY10Y-B83S 10w AC 220-240V 3000K/4000K/6500K 3CCT adjustable 1500 φ214*79mm
FSY5S-B81S 5w AC 220-240V 3000K/4000K/6500K 3CCT adjustable 800 φ214*79mm
FSY8Y-B81S 8w AC 220-240V 3000K/4000K/6500K 3CCT adjustable 1200 φ214*79mm
FSY10Y-B81S 10w AC 220-240V 3000K/4000K/6500K 3CCT adjustable 1500 φ214*79mm
